Premium 4 LED Square Work Light – 20W OSRAM, 1,764 Lumens, Flood Beam, 12/24V, IP69K

The Premium 4 LED Square Work Light is a compact, high-performance LED working lamp designed to deliver bright, wide-angle illumination in demanding professional environments.

Featuring four high-performance OSRAM LEDs, this premium work light produces an impressive 1,764 lumens from a 20W output, providing effective flood illumination for work areas, machinery and vehicle surroundings.

Its compact 2.8" square design makes it particularly suitable for commercial vehicles, agricultural machinery, construction equipment, recovery trucks, 4x4s and specialist vehicle applications where reliable lighting is essential but installation space may be limited.

The dedicated flood beam pattern distributes light across a broad area, making it ideal for illuminating loading areas, work sites, equipment and the immediate surroundings of vehicles and machinery.

Compact Design, Powerful Illumination

Despite its compact dimensions, the Premium 4 LED Square Work Light delivers an impressive 1,764 lumens, providing useful working illumination in low-light conditions.

The four OSRAM LEDs produce a broad, practical flood beam, making the lamp particularly effective for applications where close-range visibility is more important than long-distance illumination.

Its compact approximately 71 × 71mm square housing allows it to be installed discreetly on suitable vehicle bodywork, machinery, roof racks and equipment mounting points.

Whether used as an auxiliary work light on a recovery vehicle or to illuminate the working area around agricultural and construction machinery, this compact lamp provides a practical lighting upgrade.

Heavy-Duty Construction

Designed for challenging working environments, the lamp features a robust aluminium housing combined with a durable UV-resistant polycarbonate lens.

With both IP67 and IP69K protection ratings, the lamp offers excellent resistance to dust, water ingress and high-pressure cleaning, making it suitable for vehicles and machinery regularly exposed to dirt, mud, road spray and demanding weather conditions.

Its wide 10–30V operating range ensures compatibility with both 12V and 24V electrical systems, while the specified operating temperature range of -45°C to +60°C makes it suitable for use in extreme environmental conditions.

The lamp is CE marked, ECE R10 EMC approved and SAE compliant, providing confidence for professional vehicle and machinery installations.

Backed by an impressive 5-year warranty, the Premium 4 LED Square Work Light combines compact dimensions, reliable performance and heavy-duty durability in one versatile lighting solution.

Key Features

• Premium 4 LED square work light

• 4 high-performance OSRAM LEDs

• 20W power rating

• Bright 1,764-lumen output

• Wide-angle flood beam

• Compact 2.8" × 2.8" square design

• Ideal for close-range working illumination

• Wide 10–30V DC operating range

• Suitable for 12V and 24V vehicles

• Robust aluminium housing

• Durable UV-resistant polycarbonate lens

• IP67 dust and water protection

• IP69K high-pressure wash protection

• ECE R10 EMC approved

• CE marked and SAE compliant

• Operating temperature range of -45°C to +60°C

• Screw-mounted installation

• Suitable for commercial, agricultural and construction applications

• Ideal for recovery vehicles, trucks, 4x4s and specialist machinery

• 5-year warranty

Technical Specifications

• Product Type: LED Work Light / Auxiliary Flood Lamp

• LED Configuration: 4 × OSRAM LEDs

• Power Rating: 20W

• Light Output: 1,764 Lumens

• Beam Pattern: Flood

• Voltage: 10–30V DC

• Current Draw: 1.6A @ 12V

• Approvals: CE / SAE / ECE R10

• Protection Ratings: IP67 / IP69K

• Housing Material: Aluminium

• Lens Material: UV-Resistant Polycarbonate

• Lens Colour: Clear

• Lamp Shape: Square

• Dimensions: 2.8" × 2.8" (Approximately 71 × 71mm)

• Mounting: Screw Mount

• Connection Type: Built-In Connector

• Operating Temperature: -45°C to +60°C

• Warranty: 5 Years

Why Choose the Premium 4 LED Square Work Light?

The Premium 4 LED Square Work Light offers an excellent balance of compact dimensions, powerful illumination and professional-grade durability.

With 1,764 lumens of flood illumination from four OSRAM LEDs, it provides effective lighting for work areas, loading operations and machinery applications without requiring a large or bulky lamp.

Its compact 2.8" square housing makes it particularly attractive for installations where space is limited, while the broad flood beam provides practical illumination across the immediate working environment.

The combination of IP67 and IP69K protection, aluminium construction, UV-resistant lens and ECE R10 approval makes this lamp particularly well suited to demanding commercial, agricultural and industrial applications.

With a wide 10–30V operating range and 5-year warranty, it provides a versatile and dependable lighting solution for both individual vehicle installations and professional fleet applications.

A compact, premium-quality LED work light delivering 1,764 lumens of wide flood illumination, powered by OSRAM LEDs and built to withstand demanding working environments.
