APEX Black Top LED Warning Lightbar 1200mm – Low Profile ECE R65 Amber Beacon, 10–30V

The APEX Black Top LED Warning Lightbar 1200mm is the largest model in the APEX Black Top range, engineered to deliver maximum warning visibility for larger commercial vehicles, recovery trucks, highway maintenance fleets, agricultural machinery and specialist vehicles.

With its sleek black top design and extended 1200mm profile, the Apex provides exceptional 360° warning coverage while maintaining a modern, low-profile appearance. Featuring 432 high-intensity LEDs, this premium lightbar produces outstanding warning performance to maximise vehicle conspicuity in both daytime and night-time operating conditions.

Offering 20 selectable flash patterns, the Apex allows operators to select the most appropriate warning signal for a wide range of applications. Its high-output LED technology ensures excellent visibility, helping to improve safety for operators, road users and work crews in demanding roadside and off-road environments.

Manufactured using a heavy-duty aluminium housing with an impact-resistant polycarbonate lens, the Apex is built for long-term reliability in challenging working conditions. The IP67-rated construction provides excellent protection against dust and water ingress, while an operating temperature range of -45°C to +60°C ensures dependable performance in all weather conditions.

Designed for both 12V and 24V vehicles, the Apex operates across a 10–30V DC voltage range, making it suitable for a broad range of commercial and specialist vehicle applications.

Fully certified to ECE R65, ECE R10, SAE J845 and CISPR 25, the Apex Black Top Lightbar meets internationally recognised standards for warning light performance and electromagnetic compatibility, giving professional users complete confidence in its performance and compliance.

Main Features

• Premium low-profile LED warning lightbar
• 1200mm overall length
• High-output 432 LED design
• Powerful 360° amber warning coverage
• 20 selectable flash patterns
• Modern black top styling
• Suitable for 10–30V DC systems
• Compatible with 12V and 24V vehicles
• Heavy-duty aluminium housing
• Impact-resistant polycarbonate lens
• IP67 rated against dust and water ingress
• Certified to ECE R65, ECE R10, SAE J845 & CISPR 25
• Operating temperature from -45°C to +60°C
• 3-year warranty
• Dimensions: 1200 (L) x 36 (H - excl brackets) x 260 (D) mm

Ideal Applications

• Highway maintenance vehicles
• Recovery trucks
• HGVs
• Traffic management vehicles
• Utility fleets
• Agricultural machinery
• Tractors
• Construction and plant equipment
• Local authority vehicles
• Escort vehicles
• Specialist fleet vehicles

Technical Specifications

• Length: 1200mm
• Voltage: 10–30V DC
• Power Consumption: 116W
• LED Quantity: 432 LEDs
• Flash Patterns: 20
• Housing Material: Aluminium
• Lens Material: Polycarbonate (PC)
• Top Colour: Black
• Protection Rating: IP67
• Operating Temperature: -45°C to +60°C
• Approvals: ECE R65, ECE R10, SAE J845, CISPR 25
• Warranty: 3 Years

Why Choose the APEX Black Top?

The APEX Black Top 1200mm is designed for operators who require the highest level of warning visibility on larger vehicles. Its extended length and 432 high-intensity LEDs provide exceptional all-round warning coverage, making it ideal for highway maintenance vehicles, recovery fleets, utility operators and other specialist applications where maximum conspicuity is essential.

Despite its impressive output, the Apex maintains a sleek, low-profile design that complements modern commercial vehicles while reducing wind resistance and preserving a professional appearance. Built from premium materials and certified to recognised international standards, the APEX Black Top 1200mm delivers dependable performance, outstanding durability and complete peace of mind for professional users.
